Form Factor | Micro ATX |
Motherboard Compatibility | Micro ATX, Mini ITX |
Chassis | SPCC Cold Plate 0.35 mm |
Side Panel | Left Side Transparent Glass + Right Metal Panel |
Front I/O Panel | 1 x USB 3.0, 1 x USB 2.0, 1 x 3.5 mm Jack (HD Audio & Mic) |
PCI Slots | 4 |
Drive Bays | 3.5" HDD / 2.5" SSD x 1, 2.5" SSD x 1 |
Fan | 5 x 12 cm fan build-in |
Fan Mounting Locations | Rear: 1 x 12 cm Fan, Bottom: 2 x 12 cm Fan, Top: 2 x 12 cm Fan |
PSU Position | Bottom Panel |
Maximum GPU Card Length | 300 mm (11.80 Inch) |
Maximum CPU Height | 160 mm (6.3 inch) |
Radiator Cooling Provision | 240 mm Radiator Top |
Dimensions | 310 (L) mm, 195 (W) mm, 422 (H) mm |
Weight | 3.77 Kg (Without SMPS) |
Download | PDF Brochure |
In the Box | 1 x Cabinet, 1 x Screw Set, 1 x Installation Guide |
