| Form Factor | Full ATX |
| Motherboard Compatibility | Full ATX, Micro ATX, Mini ITX |
| Chassis | SPCC Cold Plate 0.4 mm |
| Side Panel | Left Side Toughened Glass Panel |
| Front I/O Panel | 1 x USB 3.0, 2 x USB 2.0, HD Audio, Mic |
| PCI Slots | 7 |
| Drive Bays | 3.5" HDD / 2.5" SSD x 2, 2.5" SSD x 1 |
| Fan | 3 x 14 cm Fan build-in, 1 x 12 cm Fan build-in |
| Fan Mounting Locations | Rear: 1 x 12 cm Fan, Front: 3 x 14 cm Fan |
| PSU Position | Bottom Panel |
| Maximum GPU Card Length | 290 mm (11.42 Inch) |
| Maximum CPU Height | 160 mm (6.3 inch) |
| Dimensions | 365 (L) mm, 190 (W) mm, 428 (H) mm |
| Weight | 4.44 Kg (Without SMPS) |
| Radiator Cooling Provision | 120mm Radiator Rear, 240 mm Radiator Top, 240 mm Radiator Front |
| Download | Download PDF |
| In the Box | 1 x Cabinet, 1 x Screw Set, 1 x Installation Guide |
